Product Description
Venetian Floor Paint is a whole ground seamless system with unique beauty, smooth surface, excellent wear resistance and natural texture. It is made up of modified polymer mortar and fast condensing material.
Features and Advantages
Seamless and natural textured pattern.
2. High compressive strength and wear-resistance, low shrinkage.
3. Fast dry and harden
4. Premixed polymer cement product, add water only.
5. Eco friendly and user friendly.
Scope of Application
It can be applied in hotels, offices, retail stores, scientific research centers, exhibition halls, restaurants and other places with high requirements for design, beauty and wear resistance of the ground, which can be directly constructed on the ceramic tiles, marble and the base surface of the terrazzo. It is suitable for the reconstruction of the old ground.
Treatment of Base substrate
1. Concrete base must be strong enough to have sufficient compressive strength (at least 25 N / mm) and tensile strength (at least 1.5N / mm). Base substrate must be clean and dry without any contaminants (such as dust, oil, grease, coating or surface treatment materials). Relative humidity should not exceed 75%, and seal the moisture to prevent upward seepage. Flatness of the base substrate must reach the SP1 level. I f you have any questions, please do a small area test first.
2. Compressive strength: minimum 25 N/mm (C25 strength of fine aggregate concrete);
3. Pulling out strength is >2.0Mpas (Note: the fine aggregate concrete is added with 6Φ- 8Φ single layer two-way reinforcing steel, and the well is lined up 10x15cm).
4. Base surface reception evenness: 2m is less than 3mm in scale range;
5. Fine aggregate concrete needs to be grinding with mechanical.
6. The difference between the base level and finish coating should be controlled within the desired thickness for construction.
7. Basal surface moisture content limit: Coating should be made within water content <6% .
8. Environmental conditions: air humidity is less than 75%; air temperature: 5-30 degrees; base surface temperature: 8-25 degrees;
9. Other requirements: No crack, no empty drum and no sand appear from the concrete base substrate.
How to maintain and cure the topping:
|
Temperature |
+10°C |
+20°C |
+30°C |
|
Walk on foot |
~ 24 hours |
~ 16hours |
~ 10 hours |
|
Light traffic |
~ 72 hours |
~ 48 hours |
~ 36 hours |
|
Final curing |
~ 12 days |
~ 7 days |
~ 7 days |
Conditions and limits
Base substrate temperature：+15 min. / +30°C max.
Temperature on site：+15 min. / +30°C max.
Base substrate humidity content：≤ 4%
Air humidity：30%-75%
Dew point: be careful of condensation! The base and not solidified ground must be 3℃ higher than the dew point temperature, so as to reduce the risk of condensation or turning whiten on the ground coating.
Venetian Floor Paint system consists from
1. Epoxy primer
2. Venetian Floor Paint
3. Polyurethane top coat sealer
Unit Coverage : 1.2kg/mm/㎡
Thickness Range: 3-8mm/㎡
Materials:
|
CAS#
|
Chemical Name
|
%
|
|
65997-15-1 |
Portlant Cement 42.5R |
25-35% |
|
14808-60-7 |
Silicone Sand |
35-45% |
|
1318-16-7 |
Bauxite Cement |
5-10% |
|
Mixture |
Polymer additive |
5-15% |
Technical Data:
|
Status |
Single component powder form |
|
Initial setting time +20℃ |
~2 hours |
|
Compressive strength after 24 hours |
~16N/m㎡ (GB/T 17671) |
|
Compressive strength after 7 days |
~23N/m㎡ |
|
Compressive strength after 28 hours |
~32N/m㎡ |
|
Flexural strength after 24 hours |
~4N/m㎡( GB/T 17671 ) |
|
Flexural strength after after 7 days |
~6N/m㎡ |
|
Flexural strength after after 28 days |
~10N/m㎡ |
|
Ball falling hardness test after 24 hours |
~40N/m㎡( GB/T 17671 ) |
|
Ball falling hardness test after 7 days |
~55N/m㎡ |
|
Ball falling hardness test after 28 days |
~70N/m㎡ |
|
Bonding adhesion strength |
~2Mpa (JC/T 907) |
|
Shaw hardness (D) 7days |
85(GB/T 2411) |
|
Wear resistant 28days |
0.1g(P60/500/100)(DIN 53 109(Taber Abrader Test) |
|
Fireproof grade |
A1f1( GB/T 8624-2006) |
|
Anti-slip (Dry friction coefficient) |
＞0.75 (GB/T 4100-2006) |
|
Applied to heat supply floor system |
Passed |
|
Shelf life |
12 months |
Package:
l Primer base : 20kg/barrel Primer hardener:5kg/barrel
l Venetian Floor Paint: 22kg/barrel
l Silicone sand(mesh 100): 25kg/bag
l Polyurethane Top Coat Sealer base: 20kg/barrel, hardener: 2kg/barrel
Storage and Shelf Life
l Kept in cool and dried place, far away from sunshine and rain.
l 12 months from date of manufacture
Technical Support
For further technical information, please contact our technical department.
Safety Advice
Please take notice of the safety information and advice given on the
packaging labels and the safety information sheet.
Disposal
In the interest of the environment, please empty all barrels completely & in accordance with local regulations.
